Profil bending machine - motorised

SCANTOOL PV-50

Item number: #500781050

Description

Scroll the mouse to zoom in on the images

Profile and pipe bending machine

• Steel welded construction frame

• 3 rolls are powered

• Hardened shafts from special steel

• Top roll hydraulic moveable

• Horizontal and vertical working position

• Standard rolls

QUOTATION REQUEST

Profil bending machine - motorised

I agree to receive the above communications by means of e-mail from Scantool Group A/S

DATASHEET

Product Specifications

Width (mm)	950
Height (mm)	1500
Length (mm)	810
Net weight (kg)	500
Voltage	3x400V-50 Hz
Number of spindle speeds	1
Motor (kW)	1,1
Roller speed (m/min.)	4,5
Diameter shaft (ø mm)	50
Diameter of top roll (mm)	152
Diameter of lower rolls (mm)	162
Hydraulic power (ton)	8
