Weld bead grinding machine for outside surfaces

75PG

Item number: #430232190

Description

Model 75PG is developed in close co-operation with the offshore industry to meet
the end user’s needs when grinding welding beads on large pipes.

With a weight of 800/850 kg the construction is heavily built for stability during continuous operations. The co...
Read More >>

×

Product Specifications

Grinder Belt (mm) 75x2000
Belt speed (m/sec) 30
Contact wheel (mm) ø200x75
Motor (HP) 7,5
Rpm 2860/3460
Voltage 3x400-440v, 50/60Hz
Weight 735
