SCANTOOL 25A
Item number: #100766000
Description
SCANTOOL 25A is a professional drill press for workshop and industry.
Standard features:
• Morse Taper No. 4
• Reversible spindle rotation
• Large working table
• Complete with auto lock chuck
• Separate emergency stop and working light
•...
Read More >>
×
QUOTATION REQUEST
Product Specifications
| Rpm | 120-3480 |
| Voltage | 3x400V - 50 Hz |
| Motor (HP) | 1,5 |
| Motor (kW) | 1,1 |
| Drilling Capacity (ø mm) | 1-32 |
| Drill chuck (mm) | 16/B16 |
| Max. spindle travel (mm) | 120 |
| Throat depth (mm) | 254 |
| Swing Capacity (mm) | 550 |
| Max. distance spindle/table (mm) | 710/1180 |
| Size of table (mm) | 475/425 |
| Size of base (mm) | 575x445 |
| Max. tilt of table (+/-) | 45° |
| Number of spindle speeds | 12 |
| Reversible | 1 |
| On Pedestal | 1 |
| Height (mm) | 1700 |
| Max. load on table (kg) | 20 kg. |
| Net weight (kg) | 125 |
