Geared head milling and drilling machine
Geared head milling and drilling machine
DM-40CA
Item number: #48000000
Description
The SCANTOOL DM-40CA is a versatile geared head milling and drilling machine with auto feed, designed for precision and performance in demanding workshop environments.
Featuring a powerful 1.1 kW motor (3x400V), MK4 spindle taper, Keyless chuck, Cross table 730 x...
Read More >>
×
QUOTATION REQUEST
Product Specifications
| Drilling capacity in steel | 32mm |
| Drilling capacity in cast iron | 40mm |
| Milling head max. | 80mm |
| Distance between base & spindle (mm) | 280 |
| Rpm | 75 – 3200 |
| Morse Taper | MT4 |
| Stroke (mm) | 120mm |
| Spindle feeds | 0.10 / 0.18 / 0.26 mm/rev. |
| Table length (mm) | 730mm |
| Table width (mm) | 210mm |
| T-slot | 14mm |
| Distance between table & spindle (mm) | 640mm |
| Longitudinal travel | 480mm |
| Vertical travel | 210mm |
| Motor (kW) | 1.1 / 1.5 kW |
| Net weight (kg) | 350 |
| Gross weight (kg) | 385 |
| Package size (L x W x H) | 830 x 760 x 1885 mm |
| Voltage | 3x400V |
